Sony KD-75X77L 75" 4K HDR 4K UHD Smart LED Google TV

Brand

Sony

Model

KD-75X77L

Operating System

Google TV

Display Features

Display Type

LED

Display Specs

Screen Size (inch, measured diagonally)

75"(74.5")

Screen Size

189 cm

Display resolution (H x V, pixels)

3840 x 2160

Viewing Angle (Right/Left)

178(89/89) degree

Viewing Angle (Up/Down)

178(89/89) degree

Display Resolution

QFHD

Aspect Ratio

16:9

Backlight type

Direct LED

Audio Specs

Channel

2ch

Audio Power Output

10W + 10W

Speaker Position

Down Firing

Bass/Treble/Balance

Balance

Speaker type

Bass Reflex Speaker

Speaker Configuration

Full Range (Bass Reflex) x 2

Digital audio out (Optical) format

Two channel linear PCM: 48kHz 16bits, Dolby Audio

Network Features

APPLE AIRPLAY

Yes

APPLE HOMEKIT

Yes

Wi-Fi Certified

Yes

Wi-Fi Standard

a/b/g/n/ac

Wi-Fi Frequency

2.4GHz/5GHz

Wireless LAN

Integrated

Energy Saving & Efficiency

Dynamic Backlight Control

Yes

Power Saving Mode / Back Light Off Mode

Yes

ECO FRIENDLY

Yes

Design Features

Stand design

Slim Wedged Stand

STAND COLOR

Black

BEZEL DESIGN

Narrow Bezel

Cable Management

Yes

Frame color

Hairline Black

Regulation and Standard Compliance

VESA® Hole Spacing Compatible

Yes

VESA® Hole Pitch(W x H)

300 x 300 mm / 11 7/8 x 11 7/8 inch

Measurements (Approx.)

Dimension of TV without Stand (W x H x D)

1686 x 969 x 72 mm / 66 1/2 x 38 1/4 x 2 7/8 inch

Dimension of Package Carton (W x H x D)

1824 x 1114 x 187 mm / 71 7/8 x 43 7/8 x 7 3/8 inch

AC Cable Length

1600mm

TV with Stand (Standard position) (W x H x D)

1686 x 1045 x 415 mm / 66 1/2 x 41 1/4 x 16 3/8 inch

STAND WIDTH (STANDARD POSITION)

1341 mm / 52 7/8 inch

Weights (Approx.)

Weight of TV without Stand

30.4 kg / 67 lb

Weight of Package Carton(Gross)

47 kg / 103.6lb.

TV with Stand (Standard position)

31.7 kg / 69.9 lb

Carton Spec

Max Qty of carton stacking (vertical)

4

Supplied Accessories

Operating Instructions

EN,FR,ES

Batteries

LR03

AC Power Cord Spec

Bundle (C7L) (US) (2pin) (flat blades)

Quick Setup Guide / Supplement CUE (GA)

EN,FR,ES,PT

Table Top Stand

Separate (Assembly required)

Voice Remote Control (Supply)

RMF-TX811U

Optional Accessories

Wallmount Bracket

SU-WL855(Refer to Country/Area Handling Chart)

Model year

Model year

2023

Audio Features

Clear Phase

Yes

S-Master

S-Master Digital Amplifier

Dolby audio format support

Dolby Audio

HDMI Audio Return Channel(ARC)

Yes (eARC/ARC)

Auto Mute (on no signal)

Yes

HDMI input Audio format

Two channel linear PCM: 32/44.1/48kHz 16/20/24bits, Dolby Audio

ARC output format

Two channel linear PCM: 48kHz 16bits, Dolby Audio, Dolby Atmos

Speaker Type-2

X-Balanced Speaker

Inputs and Outputs

HDMI Signal

4096x2160p(24,60Hz), 3840x2160p(24,30,60Hz), 1080p(30,60Hz), 1080/24p, 1080i(60Hz), 720p(30,60Hz), 720/24p, 480p, 480i

HDCP

HDCP2.3(for HDMI1/2/3)

Bluetooth profile support

Version 5.0,HID/HOGP/A2DP/AVRCP/SPP

4K 60P High-Quality formats

HDMI IN1, IN2, IN3 ports for 4K(up to 18Gbps) signal

AC Power Input

C8 INLET(REAR)

RF (Terrestrial/Cable) Connection Input(s)

1(Side)

Composite Video Input(s)

1(Side, mini jack)

HDMI inputs total

3(3Side)

Analog Audio Input(s) (Total)

1(Side Analog Conversion)

Digital Audio Output(s)

1(Side)

USB ports

2(Side)

Ethernet inputs

1(Side)

HDMI PC Input Format

640x480(31.5kHz,60Hz), 800x600(37.9kHz,60Hz), 1024x768(48.4kHz,60Hz), 1280x1024(64.0kHz,60Hz), 1152x864(67.5kHz,75Hz), 1600x900(55.9kHz,60Hz), 1680x1050(65.3kHz,60Hz), 1920x1080(67.5kHz,60Hz)

Power

Power Requirements (voltage)

AC 120V for UL cUL AC 110-240V for other

Power Requirements (frequency)

60Hz for UL cUL 50/60Hz for other

Rated Power Consumption

315 W

Power Consumption (in Standby)

0.5 W

Video Features

Picture modes

Vivid,Standard,Cinema,Game,Graphic,Photo,Custom

Auto Wide

Yes

Wide Mode

Auto/Wide zoom/Normal/Full/Full Pixel/Zoom/14:9,Full Pixel

4:3 Default

Yes

Video Processing

4K X-Reality Pro

Motion enhancer

Motionflow XR 240 (Native 60Hz)

24p True Cinema

Yes

Live Colour™ Technology

Yes

PhotoTV HD / BRAVIA for China

Yes

CineMotion/Film Mode/Cinema Drive

Yes

4K Processor

4K Processor X1

HDR (High Dynamic Range) compatibility

Yes(HDR10,HLG)

Panel Refresh Rate (Native Hertz)

60Hz

Dynamic Contrast Enhancer

Yes

Features for PlayStation®5 Auto HDR Tone Mapping

Yes

Features for PlayStation®5 Auto Genre Picture Mode

Yes

Convenience Features

Features specified in HDMI2.1

eARC/ALLM

Electronic Program Guide (EPG)

Yes

USB playback codecs

MPEG1:MPEG1/MPEG2 PS:MPEG2/MPEG2 TS(HDV,AVCHD):MPEG2,AVC/MP4(XAVC S):AVC,MPEG4,HEVC,AV1/AVI:MotionJpeg/ASF(WMV):VC1/MOV:AVC,MPEG4/MKV:AVC,MPEG4,VP8,HEVC/3GPP:MPEG4,AVC/MP3/ASF(WMA)/LPCM/WAV/MP4AAC/FLAC/JPEG,WEBM:AV1/AC4/ogg/AAC

Audio Description

Yes

Text Magnification

Yes

Accessibility Shortcut

Yes

Switch Access

Yes

Auto Picture Mode

Yes

Text Input Language

ARA / ENG / FIN / FRA / GER / HEB / HIN / ITA / JPN / KOR / NOR / PER / POR / RUS / SPA / THA / VIE / zh_CN / zh_TW / ZHO(Simplified) / ZHO(Traditional) / zh_HK

Chromecast built-in

Yes

Voice Search

Yes

Application Store

Yes (Google Play Store)

i-Manual

Yes

Parental Control

Yes

Channel Block (with password)

Analog & Digital

Show/Hide Channels

Yes(Digital&Analog)

On Screen Clock

Yes

Sleep Timer

Yes

On/Off Timer

Yes

USB drive format support

Yes (Supported File System: FAT16/FAT32/NTFS)

Display Language

AFR / ARA / BEN / ENG / FRA / GUJ / HIN / IND / KAN / MAL / MAR / PAN / PER / POR / RUS / SPA / SWA / TAM / TEL / THA / VIE / zh_CN / zh_TW / zh_HK / ZUL

Auto Shut-off

Yes

TALKBACK

Yes

Auto Low Latency Mode (ALLM)

Yes (for HDMI3)

Control for HDMI (HDMI CEC)

Yes

General Features

Closed Captions (Analog)

Yes

Closed Captions (Digital)

Closed Caption

Demo Mode

Yes(e-POP Only)

SMART TV

Google TV

BRAVIA CORE

Not supported

Style

LED 70" - 79"
